Ultra 210W UNIFI UBIQUITI 8-Port Gigabit POE Switch
Rp4.551.000
Deskripsi
TECHNICAL SPECIFICATION
Specification
| Model | USW-Ultra-210W |
| Ports | 8 1 GbE RJ45 (7 PoE+; 1 PoE++ input) |
| Max. PoE Output | Up to PoE+ |
| Total PoE Availability | PoE++ input: 42W PoE+ input: 16W 60W PoE adapter input: 42W 60W AC adapter input: 52W 210W AC adapter input: 202W |
| Layer Type | Layer 2 |
| Switching capacity | 16 Gbps |
| Total Non-Blocking Throughput | 8 Gbps |
| Forwarding rate | 12 Mpps |
| Supported VLANs | 256 |
| MAC address table | 4000 |
| Dimensions (W x D x H) | 203 x 76 x 33 mm |
| Max. PoE Wattage per Port by PSE (PoE+) | 30W |
| Max. Power Consumption | 9W (Excluding PoE Output) with PoE input 8W (Excluding PoE Output) with adapter input 210W (Including PoE Output) with 210W AC adapter input |
| Power Method | (1) AC/DC adapter (Included) (1) PoE++ |
| Power Input Method | DC Input PoE |
| Power Supply | AC/DC, external, 210W |
| Supported Voltage Range | 50—57V DC/PoE |
| Management | Ethernet |
| Heat Dissipation (Excluding PoE Output) | 30.708 BTU/hr 27.296 BTU/hr |
| Enclosure Material | Polycarbonate |
| Ambient Operating Temperature | PoE++ input: -30 to 60 C (-22 to 140 F) 210W AC adapter input: -20 to 60 C (-4 to 140 F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
